1-7-function electro-hydraulic control, automatic opening/closing (LogicControl lever)
2- 7 sections 48 triple nozzle holders at 20''
(For 110 or 120 degree nozzle)
3-Rateking Plus 7 Section Rate Controller *
Hypro 9306C-HM1CUB Hydraulic Centrifuge, Tungsten Seals
Pump 13 gpm oil 85 gpm at 100 PSI
802-11 Flow Meter at 492 liters/min (3 to 130 gal/min)
Rateking Plus Micro-Track Rate Controller | 22-Pin Cable
4-Manual adjustable axle - 320/90R46 wheels for F1000 and F1250
90'' to 120'' recommended
Wheel spacing on level ground. 64'' to 120''
5-Manual adjustable axle - 380/90R46 wheels for:
F1000, F1250 with air assist
F1500 with or without air assist - 90'' to 120'' recommended
Wheel spacing on level ground. 64'' to 120'' for F1000 and F1250
Wheel spacing on level ground. 72'' to 120'' for F1500
6-Manual Adjustable Axle - 380/90R46 Wheels for F1500
Recommended spacing of 90'' to 120''
7-Drain with ball valve and cam stopper
8-Filtration assembly for ramp section
9-Emergency kit - Metal box with essentials
emergency troubleshooting
10-Safety valve - Ball valve at the inlet of each connection
to the tank
11-2'' Fill Inlet Quick Coupler and Shut-Off/Non-Return Valve for Main Tank
12-Set of road lights without brake lights, “slow moving vehicle” identification and safety chain.
